TENDA MX3-3-PACK AX1500 Dualband Mesh Router

      Hardware

Standard&Protocol

  IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

CPU

  1GHz CPU

RAM

  128MB

Interface

  10/100/1000Mbps WAN port*1
  10/100/1000Mbps LAN port*1

Antenna

  2 x 3dBi Internal antenna

Button

  1 x Reset Button
  1 x MESH Button

Power

  Input: AC 100-240V~50/60Hz
  Output:DC 12V⎓1A

LED Indicator

  SYS*1

Dimension

  90*90*93 mm (3.54*3.54*3.65 in.)

      Wireless

Wireless Standard

  2.4GHz：IEEE 802.11n/b/g
  5GHz：IEEE 802.11ax/ac/n/a

Data Rate

  5GHz:1201Mbps
  2.4GHz:300Mbps

Frequency

  2.4GHz & 5GHz

Transmission Power

  CE:
  <20dBm(2.4GHz)
  <23dBm(5GHz)
  FCC:
  <30dBm(2.4GHz)
  <30dBm(5GHz)

Basic Functions

  OFDMA
  MU-MIMO
  Beamforming

Wireless Security

  WPA2-PSK
  WPA3-SAE/WPA2-PSK
  Wireless Encryption Disable and Enable
  WPS Fast Connection

      Software

Internet Connection Type

  PPPoE, Dynamic IP, Static IP
  PPPoE(Russia), PPTP(Russia), L2TP(Russia)
  Unify,Maxis,Maxis-special,Celcom,Digi

Network Protocol

  IPv4&IPv6

Operating Mode

  Router Mode,AP Mode

Parental Control

  URL Filter
  Time Limit

DHCP

  DHCP Server
  DHCP Client List
  DHCP Reservation

Virtual Server

  Port Forwarding
  DMZ Host
  UPnP

Firewall

  Forbid UDP Flood Attack
  Forbid TCP Flood Attack
  Forbid ICMP Flood Attack
  Forbid WAN Ping from Internet

DNS

  DynDNS, no-ip, oray, 88ip

VPN

  IPsec Pass Through
  PPTP Pass Through
  L2TP Pass Through
  PPTP VPN Server
  PPTP VPN Client
  L2TP VPN Client

Special Features

  WPA3
  TR069
  Tenda EasyMesh
  Unify 2.4 GHz & 5 GHz
  Smart LED on/off
  Amazon Alexa
  One-button Fault Diagnosis
  Broadband Account Migration
  Tenda App: Local and Remote ManagementSpeed Test
  Monthly Report

Other Function

  IPTV
  IPv6
  Guest Network
  System Log
  Remote Web Management
  MAC Clone
  Backup & Restore configurations
  Support automatic access detection
  Firmware upgrade online

      Others

Temperature

  0 ~ 40 ℃

Humidity

  10%~90% RH non-condensing

Certification

  CE
  FCC
  RoHS

Package Contents

  Mesh3X*3
  Quick Installation Guide*1
  Gigabit Ethernet Cable*1
  12/1A Power Adapter*3
